Powerful, efficient, and compact.
The TCD 4.1 – With 85 up to 115 kW power output, ideal for your application.
| POWERFUL | Up to 115 kW & 609 Nm |
| LOW EMISSIONS | EU Stage V, Tier 4f, CN IV & HVO certified |
| MODULAR | Wide range of applications due to a variety of options |
| VERSATILE | Agricultural & EDG – Version* (Stage IIIA, Tier 3) |
| POWERPACK | Modular, compact & ready for installation |
POWER / TORQUE CURVES
TECHNICAL DATA
| ENGINE TYPE | TCD 4.1 | |
|---|---|---|
| No. of Cylinders | 4 | |
| Displacement | I | 4.038 |
| Max. Nominal speed | min−1 | 2300 |
| Aspiration | Turbocharger with intercooler | |
| Power Output acc. ISO 14396 | kW | 80 - 115 |
| At Speed | min−1 | 2300 |
| Max. Torque | Nm | 609 |
| At Speed | min−1 | 1600 |
| Min. Idling Speed | min−1 | 600 |
| Weight (DIN 70020 Part 7A) | kg | 400 |
DIMENSIONS
| ENGINE TYPE | A | B | C | DOC/DPF (D) | DOC/DPF (L) | SCR (D) | SCR (L) | DOC/DPF | SCR | |
|---|---|---|---|---|---|---|---|---|---|---|
| TCD 4.1 | mm | 852 | 643 | 884 | 246 | 698 | 246 | 659 | 🔴 🟥 | 🔴 🟥 |
