Powerful, efficient, and compact.
The TCD 12.0 V6 – With 240 up to 390 kW power output, ideal for your application.
| POWERFUL | Up to 390 kW & 2130 Nm |
| LOW EMISSIONS | EU Stage V, Tier 4f, CN 4 & HVO certified |
| MODULAR | Wide range of applications due to a variety of options |
| VERSATILE | Flat compact version available |
| POWERPACK | Modular, compact & ready for installation |
POWER / TORQUE CURVES
TECHNICAL DATA
| ENGINE TYPE | TCD 12.0 V6 | |
|---|---|---|
| No. of Cylinders | 6 | |
| Displacement | I | 11.906 |
| Max. Nominal speed | min−1 | 2100 |
| Aspiration | Turbocharger with charge air cooler | |
| Power Output acc. ISO 14396 | kW | 240 - 390 |
| At Speed | min−1 | 2100 |
| Max. Torque | Nm | 2130 |
| At Speed | min−1 | 1400 |
| Min. Idling Speed | min−1 | 1000 |
| Weight (DIN 70020 Part 7A) | kg | 995 |
DIMENSIONS
| ENGINE TYPE | A | B | C | DOC/DPF (D) | DOC/DPF (L) | SCR (D) | SCR (L) | DOC/DPF | SCR | |
|---|---|---|---|---|---|---|---|---|---|---|
| TCD 12.0 V6 | mm | 1198 | 948 | 1169 | 385 | 1364 | 385 | 1364 | 🔴 | 🟥 |
