Powerful, efficient, and compact.
The G 2.2 & G 2.9 – With 26 up to 42 kW power output, ideal for your application.
| POWERFUL | Up to 42 kW & 160 Nm |
| LOW EMISSIONS | EU Stage V & Tier 2 with 3-way catalyst |
| MODULAR | Wide range of applications due to a variety of options |
| VERSATILE | LPG, CNG (G 2.2) & Gasoline, LPG, Bi-Fuel (G 2.9) |
POWER / TORQUE CURVES
TECHNICAL DATA
| ENGINE TYPE | G 2.2 | G 2.9 | |
|---|---|---|---|
| No. of Cylinders | 3 | 4 | |
| Displacement | I | 2.2 | 2.9 |
| Max. Nominal speed | min−1 | 2800 | 2800 |
| Aspiration | Natural | Natural | |
| Power Output acc. ISO 14396 | kW | 26 - 41.5 | 44.1 - 54.5* |
| At Speed | min−1 | 2800 | 2800 |
| Max. Torque | Nm | 160 | 209 |
| At Speed | min−1 | 1600 | 1600 |
| Min. Idling Speed | min−1 | 900 | 900 |
| Weight (DIN 70020 Part 7A) | kg | 208 | -- |
DIMENSIONS
| ENGINE TYPE | A | B | C | 3-way catalyst w/o insulation (D) | 3-way catalyst w/o insulation (L) | 3-way catalyst w. insulation (D) | 3-way catalyst w. insulation (L) | 3-way catalyst | |
|---|---|---|---|---|---|---|---|---|---|
| D 2.2 | mm | 576 | 481 | 708 | -- | -- | -- | -- | -- |
| TD 2.2 | mm | 578 | 636 | 745 | 199 | 470 | -- | -- | 🔴 🟥 |
| TCD 2.2 | mm | 576 | 630 | 719 | 199 | 506 | -- | -- | 🔴 🟥 |
